J-2103 Plus Multi Boring Machine

665000 INR/Piece

Get a Price/Quote

Product Details:

Power Source Electricity
Operating Type Automatic
Power 6 Horsepower (HP)
Pressure 6 hp kgf/cm2
Dimension (L*W*H) 3048x1143x1675 Millimeter (mm)
Weight (kg) 900 Kilograms (kg)
Warranty 1 YEAR
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

J-2103 Plus Multi Boring Machine Price And Quantity

Minimum Order Quantity 1 Piece
Price 665000 INR/Piece

J-2103 Plus Multi Boring Machine Product Specifications

Weight (kg) 900 Kilograms (kg)
Warranty 1 YEAR
Dimension (L*W*H) 3048x1143x1675 Millimeter (mm)
Usage/Applications Industrial
Power 6 Horsepower (HP)
Pressure 6 hp kgf/cm2
Power Source Electricity
Operating Type Automatic

J-2103 Plus Multi Boring Machine Trade Information

Payment Terms Cash on Delivery (COD) Telegraphic Transfer (T/T) Cash Advance (CA)
Delivery Time 60 Days
Packaging Details WELL PACKED CARDBOARD AND BUBBLE,POLYTHENE COVER
Main Export Market(s) Asia
Main Domestic Market North India
Certifications An Iso 9001:2015 Certified Coompany CE Certified Company

Product Description

J-2103 Plus Multi Boring Machine we put forward is an advanced technology woodworking machine engineered to be utilized for enlarging the size of existing hole wooden particle board or plywood panel. Owing to its smooth boring mechanism, ergonomic design, and strong structure, it performs automatically and constantly by consuming low electric energy. Plus, it is effortless to put on required place, and easy to operate due to its ideal dimension and weight. Additionally, J-2103 Plus Multi Boring Machine can be availed by clients at industry leading prices.

Specification

Air pressure required	6 to 7
Elect. Motor / Total Power	3 x 2 = 6
Machine Dimensions (L x B x H)	2900 x 1130 x 1500
Max. size of workpiece	1850 x 640
Max. working thickness	60
Minimum center distance between 2 vertical heads	150
No. of spindle head	Three
No. of spindles per head	21
Shank diameter of drill	10
Total spindles	21 + 21 + 21 = 63
Country of Origin	Made in India
Drilling Depth	0-50 (Drill length 70 mm)
