J-724 (H) combi planer

Name: J-724 (H) combi planer
Brand: MOONLIT INDUSTRIES (REGD.)
Price: 273000 INR
Availability: InStock

Price 273000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

J-724 (H) combi planer Specification

Machine Type
Planer Cum Thicknesser

Cooling System
Air Cooled

Voltage
415 V

Lubricating System
Manual Greasing

Noise Level
Medium

Power Rating
2.2 kW

Production Capacity
Continuous

Frequency
50 Hz

Features
Multi-Operation - Planer, Thicknesser, Router & Groover

Control System
Manual Lever/Knob Controls

Frame Type
Heavy Duty Cast Iron

Accuracy
0.05 mm

Model No
J-724 (H)

Operating Temperature
0C to 45C

Motor Power
3 HP

Drive
Belt Driven

Product Type
Wood Working Machines

Technology
Manual/Mechanical

Power Source
Electric

Operating Type
Semi-Automatic

Power
3 HP

Pressure
Standard Atmospheric

Surface Treatment
Coated

Dimension (L*W*H)
63 x 33 x 41

Weight (kg)
525 kg

Color
Green

Warranty
1 Year

Usage & Applications
Industrial

Cutter Block Material
Alloy Steel

Cutter Block Diameter
95 mm

Maximum Planning Width
330 mm

Number of Knives
3

Table Length
63 inch

Finish Provided
Smooth Surface Finish

Thicknessing Table Travel
150 mm

Maximum Rebating Depth
12 mm

Feed Speed
7 m/min

Maximum Thicknessing Width
305 mm

Safety Features
Overload Protection, Emergency Stop

Maximum Depth of Cut
8 mm

Cutter Block Speed
4500 rpm

Main Spindle Size
1 inch

J-724 (H) combi planer Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
3 Pieces Per Day

Delivery Time
7 Days

Main Domestic Market
Uttarakhand

About J-724 (H) combi planer

Discover the J-724 (H) combi planer, a hot-selling, matchless solution specializing in majestic woodwork precision. Boasting a maximum planing width of 330 mm, a robust 3 HP motor, and 4500 rpm cutter block speed, this champion machine delivers a smooth, coated surface finish every time. Benefit from features like overload protection, a heavy-duty cast iron frame, and multiple operations-planer, thicknesser, router, and groover. Personalise your workshop with continuous, reliable performance. Secure this bargain for industrial-scale production and enjoy seamless craftsmanship with a 1-year warranty!

J-724 (H): Primary Advantages & Applications

The J-724 (H) combi planer stands out with its superior accuracy of 0.05 mm, ensuring matchless output for industrial environments. Its heavy-duty cast iron frame provides stability during continuous operation while accommodating a wide range of applications-from standard planing and rebating to sophisticated routing and grooving. Championing operator safety, this model includes overload protection and emergency stop functions. Its semi-automatic technology coupled with manual lever/knob controls offers majestic flexibility and operational ease.

J-724 (H): Samples, Policies & Certifications

Sample units of the J-724 (H) combi planer are available upon request, subject to our sample policy and verified purchase order. Each machine is meticulously packaged for secure goods transport, ensuring safe delivery to your doorstep. As a trusted manufacturer, exporter, and trader in India, we provide certifications validating compliance with industrial safety and quality standards. Partner with us for a hassle-free sampling experience, reliable packaging, and swift dispatch on your next industrial machinery purchase.

FAQ's of J-724 (H) combi planer:

Q: How does the J-724 (H) combi planer ensure operator safety?

A: The J-724 (H) combi planer is equipped with overload protection and an emergency stop function, providing quick response options to ensure user safety during operation.

Q: What are the primary benefits of using this combi planer in industrial applications?

A: This machine offers multi-operation capabilities (planer, thicknesser, router, groover), precise accuracy, continuous production capacity, and a robust alloy steel cutter block, making it ideal for diverse and demanding industrial woodwork tasks.

Q: Where can the J-724 (H) planer be applied in a manufacturing plant?

A: It is well-suited for workshops, assembly lines, and production units requiring high-accuracy planning, thicknessing, routing, and grooving on various types of wood.

Q: What is the process for obtaining a sample of this product?

A: Samples can be requested through a formal purchase order. The sample is securely packaged and shipped as per our sample policy, ensuring safe goods transport to your facility.
